Crate V33H Tube Guitar Amplifier Head

Order your Crate V33H Tube Guitar Amplifier Head and enjoy 0% Interest Payment Plans, Free Shipping, Free Extended Warranty and 45 Day Money Back Guarantee.
Sorry! This item is no longer available.
Out of Stock:
Product Description

The Crate V33H Tube Guitar Amplifier Head provides two channels delivering 33 watts of all tube Class A British tone.
The V33H produces the chiming clean and harmonic-laden overdrive that discriminating pickers expect from four EL84 cathode-biased output tubes. The new V33H's foot-switchable boost function, 3-band EQ, fluid channel switching and spring reverb deliver massive Class A tone in a head that is ready for the speaker cabinet of your choice.

Crate V33H Features

  • 33 watts RMS
  • Class A, all tube circuitry
  • Two channels
  • 4 x EL84 output tubes, cathode biased
  • Spring reverb
  • Footswitchable boost function

Product Specifications
Crate V33H Specifications

  • Output Power Rating: 33 W rms at 10% THD, 8 ohm load, 120 VAC
  • Input Impedance: 700k Ohms
  • Signal-to-Noise Ratio: 42 dB, Typical (Clean Channel only)
  • Gain:
    • Overdrive Channel: 102 dB, all controls at 10
    • Clean Channel: 56 dB, all controls at 10
  • EQ:
    • Treble: 12 dB range at 6 kHz
    • Middle: 10 dB range at 1 kHz
    • Bass: 8 dB range at 150 Hz
  • Boost: 10 dB at 900 Hz
  • Presence: 8 dB at 10 kHz
  • Preamp Tubes: (3) 12AX7
  • Power Tubes: (4) EL84
  • Power Requirements: 90-132 VAC, 60 Hz, 85 VA
  • Size (H x W x D): 8.25 x 24.25 x 9.15 inches
  • Weight: 25.4 lbs.


Helpful Info about the Manufacturer
Phone:  800-738-7563 Warranty:  Effective September 17, 2010: 1 Year Electronic; Discontinued and B-Stock Products: 90 Days
