Crate V33H Tube Guitar Amplifier Head

Easy Payments, Fastest Shipping, Best Customer Service and Free Extended Warranty on Crate V33H Tube Guitar Amplifier Head. AmericanMusical.com makes it simple to buy gear!
Sorry! This item is no longer available.
Out of Stock:
See all items from Crate
Product Description

The Crate V33H Tube Guitar Amplifier Head provides two channels delivering 33 watts of all tube Class A British tone.
The V33H produces the chiming clean and harmonic-laden overdrive that discriminating pickers expect from four EL84 cathode-biased output tubes. The new V33H's foot-switchable boost function, 3-band EQ, fluid channel switching and spring reverb deliver massive Class A tone in a head that is ready for the speaker cabinet of your choice.

Crate V33H Features

  • 33 watts RMS
  • Class A, all tube circuitry
  • Two channels
  • 4 x EL84 output tubes, cathode biased
  • Spring reverb
  • Footswitchable boost function

Product Specifications
Crate V33H Specifications

  • Output Power Rating: 33 W rms at 10% THD, 8 ohm load, 120 VAC
  • Input Impedance: 700k Ohms
  • Signal-to-Noise Ratio: 42 dB, Typical (Clean Channel only)
  • Gain:
    • Overdrive Channel: 102 dB, all controls at 10
    • Clean Channel: 56 dB, all controls at 10
  • EQ:
    • Treble: 12 dB range at 6 kHz
    • Middle: 10 dB range at 1 kHz
    • Bass: 8 dB range at 150 Hz
  • Boost: 10 dB at 900 Hz
  • Presence: 8 dB at 10 kHz
  • Preamp Tubes: (3) 12AX7
  • Power Tubes: (4) EL84
  • Power Requirements: 90-132 VAC, 60 Hz, 85 VA
  • Size (H x W x D): 8.25 x 24.25 x 9.15 inches
  • Weight: 25.4 lbs.


Helpful Info about the Manufacturer
Phone:  800-738-7563 Warranty:  Effective September 17, 2010: 1 Year Electronic; Discontinued and B-Stock Products: 90 Days
