Item #: YAM EMX312SC PAK Mfr#

Yamaha EMX312SC Powered Mixer PA Package with BR15 Speakers

Easy Payments, Fastest Shipping, Best Customer Service and Free Extended Warranty on Yamaha EMX312SC Powered Mixer PA Package with BR15 Speakers. AmericanMusical.com makes it simple to buy gear!
  • YAM EMX312SC PAK Product Image

See all items from Yamaha
Product Description

The Yamaha EMX312SC is a 2x300 Watt powered mixer with built-in effects. With the power for mid-to-large venues – 300 watts + 300 watts – and the added advantage of one-knob compression on mono channels (like its bigger brother the EMX512SC), the EMX312SC may be the model you need. All three mixers in this series offer four mono microphone channels (with phantom power) or line input, plus four channels that can function either as mono microphone inputs or stereo line channels. All models also feature a power mode switch that lets you use the two power channels as a stereo amplifier, or one for the main speaker(s) and the other to drive monitors. This special package is now available with Yamaha BR15 speakers.

Yamaha EMX Series Powered Mixers - Integrated Solutions for Superior Live Sound
Experienced musicians, performers, speakers, and club operators know the importance of a high-quality sound system with the right features and performance to deliver their sound. Where portability and convenience are important criteria, a system based on a high-performance Yamaha EMXseries powered mixer is definitely the way to go. In one integrated, portable unit you have a mixer to combine and balance your microphone, instrument, and line sources, effects to refine and polish your sound, and power to drive the main speakers and even monitor speakers as well. But that's nowhere near the whole story - Yamaha EMX-series Powered Mixers offer a range of features that let you mix, process, and deliver your sound with maximum quality and creative control ... and, of course, that unrivalled Yamaha sound.

Features for Superior Sound and Convenience

    Great Yamaha Sound
    Yamaha is a leader in the field of professional live sound for a very good reason: we deliver the sound and performance that the pros demand. The EMX-series powered mixers are no exception. They're built at the same standards of sonic performance and rugged reliability that makes Yamaha the first choice for live sound applications from schools to stadiums around the globe.

    One-knob Compression on Mono Channels (EMX312SC & EMX512SC)
    All four monaural mic/line channels on the EMX312SC and EMX512SC feature built-in compressors that can help to bring vocals to the front of the mix, give your guitars extra smoothness and presence, deliver more authoritative bass sound, and generally refine your mixes in a multitude of ways. These one-knob compressors are simple to use, too. There's no need to juggle multiple attack, threshold, makeup gain, and other controls - just set the COMP control for the amount of compression you need.

    SPX Digital Effects
    The EMX212S, EMX312SC, and EMX512SC all feature a selection of 16 top-quality Yamaha SPX effects - including reverb, echo, chorus, flanger, phaser, and even distortion - that can add the final touch to your live presentation. Yamaha SPX digital effects are widely recognized as being some of the finest available, and the effects provided in the EMX mixers live up to that reputation.

    Built-in Graphic EQ
    Graphic equalizers are provided for both the main and monitor channels, so you can effectively control feedback or tailor the sound to match the room and program material.

    Stand-by Mode
    When you're done with a set simply engage the stand-by mode to mute all mono channels while leaving the 2-track inputs active for background music playback while you're taking your break.

    Feedback Channel Locating (FCL) System
    FCL System indicator LEDs at the top of each channel light if the corresponding channel goes into feedback, so you won't have to fumble around searching for the channel that needs adjustment.

    12 Inputs
    All three mixers in this series offer a total of 12 input channels - four for monaural microphone (incl. Phantom Power) or line input, plus four pairs that can function either as monaural microphone inputs or stereo line inputs - providing you with a versatile mix of input capabilities for a wide range of applications. If you need only microphone inputs you can use up to eight mic channels. Or if, for example, you want to play recorded background music during breaks (that's one stereo channel), and you have a keyboard player with a stereo-output keyboard (that's one more stereo channel), you still have six mic/line inputs. If you use all four stereo pairs to handle stereo line sources you have four channels available for mono mic or line input. This is a very versatile system that can adapt to your needs.

    High Power For Main and Monitor Speakers
    These powered mixers certainly don't skimp on power. From the EMX212S with 200 watts per channel to the EMX512SC with a solid 500 watts per channel, there's a power configuration to suit any application and venue. All models also feature a power mode switch that lets you use the two power channels as a stereo amplifier, or you can use one of the channels for the main speaker(s) and the other to drive monitors with a separate monitor mix set up via the channel MONITOR controls.

    Yamaha Speaker Processing
    Yamaha Club-series speakers are fine performers in their own right, but with Yamaha Speaker Processing you get extra-smooth highs and enhanced low-frequency output.

    Durable, Lightweight Design
    The EMX powered mixers offer the ideal combination of outstanding sound performance and easy handling. They're lightweight — only 10 kilograms (22lbs.) — and feature conveniently located handles for maximum carrying comfort. They're also built tough to withstand the rigors of use on the road.

Yamaha BR15
The new BR-Series from Yamaha combines affordability with high performance. Five BR models are designed to fit the budgets of performing musicians, small churches, and schools, while delivering the full frequency response and high output of more costly systems. While "BR" presents "bass reflex", it also proves very appropriate for describing the line's advanced feature set... Built Right: Combining their knowledge of acoustics and advanced computer controlled woodworking, Yamaha Music Manufacturing in Thomaston, Georgia, crafts the BR line of sound reinforcement loudspeakers to exacting standards. Each model's large steel handles, corner protectors, and built-in pole sockets, assure both durability and flexibility. Better Response: BR cabinets are carefully designed for the best balance of small, easy to handle size and great low-frequency response, using Bass Reflex technology. High-frequency response is also enhanced with a 1" new titanium HF driver and 90° by 40° non-resonant horn. Best Reliability: All BR-Series models are covered by a three-year warranty. With integral protection circuitry built into the passive crossover, you can expect a long life of high output and minimal distortion. Whichever model you choose, your message is sure to be heard using BR-Series loudspeakers... and you can take the savings to the bank!

Product Specifications

Yamaha EMX312SC Specifications

  • Maximum Output Power @ 0.5 % THD at 1 kHz:
    • 300 Watts at 4 Ohms
    • 190 Watts 8 Ohms
  • Frequency Response: -3, 0, 1 dB
    20 Hz-20 kHz, ref to the nominal output level @ 1 kHz
  • Total Harmonic Distortion: Less than 0.5 % (THD+N)
    +14 dB @ 20 Hz, 1 kHz, 20 kHz, GAIN control: all nominal
  • Hum & Noise*1:
    • Equivalent Input Noise, -115 dBu
    • Rs = 150 Ohms CH 1-4 MIC/LINE: MIC
  • Crosstalk @ 1 kHz: -65 dB
  • Input Connectors:
    • Channels 1 thru 4: XLR and Phone
    • Channels 5 and 6, 7 and 8: XLR and Phone
    • Channels 9 and 10, 11 and 12: XLR and RCA
  • EQ: HIGH, MID, LOW
  • Phantom Power: 15 V
  • Graphic Equalizer: 7 Band (125, 250, 500, 1 k, 2 k, 4 k, 8 kHz): Main (Stereo) and Monitor
  • Digital Effects: SPX Digital Multi Effector (24 bit AD/DA, 32 bit Internal Processing): 16 Programs
  • Power Amplifier Modes:
    • Main L/R
    • Main (L+R)/Monitor
  • Foot Switch: Effect On-Off
  • Dimensions (W x D x H): 17-3/8 x 10-3/4 x 11-1/4 inches (442 x 274 x 286 mm)
  • Weight: 22 lbs. (10 kg)

*1 Hum & Noise are measured with a 6 dB/octave filter @ 12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.

Yamaha BR15 Specifications

  • Woofer: 15"
  • Tweeter (diaphragm): 1" titanium
  • Frequency Response (-10dB): 60Hz-20kHz
  • Power Handling (noise*/program/peak): 200/400/800 Watts
  • Nominal Impedance: 8 ohms
  • Nominal Dispersion: 90° H x 40° V C.D.
  • Sensitivity (1W, 1m): 98dB
  • Input Connectors: 2 x 1/4" Phone
  • Dimensions (Approximate):
    • W: 19"
    • H: 25 3/4"
    • D: 14 1/2"
  • Weight: 46.9 lbs.

    * (EIA RS426)



Helpful Info about the Manufacturer
Phone:  714-522-9000 Warranty:  7 Years: DSR, DXR, and DXS Speakers; 3 Years: Power Amps, Speakers; YDP, CP, N100, PF & P Series Digital Pianos
1 Year: Digital Mixers, Studio Monitors, Analog Consoles, Powered Mixers, Multi-Track Recorders, Digital Effect Processors, Signal Processors, Synthesizers, Drum Machines, Sequencers, Tone Modules, Portable Keyboards, Guitars, Drum Shells & Hardware, Drum Shell Finish.
1 Yr Parts, 90 Days Labor: Drum Pedals, Cymbal Stands, Rack Systems
Jim from Canada
Overall Rating
General
Subject
I dont think you coud find a better quality p.a. system for less money. I use this system for D.J ,
General
Your general opinion of this product.
Highly recommend if you do not have experience in live audio gigs.
Discussions
Currently there are no discussions available for this item.
0% Interest - EZ Payments!

3 Payments of
$299.67
MSRP: $1,217.00
Save:26%
$899.00
In Stock!
Your Kit Includes:
  • 1 Yamaha EMX312SC Powered Mixer with Effects New
  • 2 Yamaha BR15 PA Speaker New
