Roland Fantom XR Synthesizer Sampler Sound ModuleThe Roland Fantom XR delivers the power of the new Fantom-X series keyboards in a convenient 1U rack.
With room for over 1GB of sounds - 128MB internal wave ROM and room for six SRX expansions, this affordable module sets a new standard for expandability. The Fantom XR supports full-blown user, and provides .WAV and .AIFF compatibility for loading samples via USB. The Fantom XR comes with 16MB memory expandable to 528MB with optional DIMMs. The XR has 3 MFX processors (including modeling), plus separate reverb, chorus and mastering effects. Save all your work through USB or with up to 1 GB of PC card storage. The USB port functions as a MIDI interface. Just MIDI it up to your sequencer of choice, and let the Fantom XR automatically sync up all your audio loops to tempo using a high-quality realtime time stretching algorithm.
You can even record linear audio phrases and play them back from RAM like a digital recorder. With the bundled editing software (and the USB interface), you have everything you need to turn any computer into a full blown AUDIO/MIDI studio with just any old MIDI controller. Back panel: MIDI in/out/thru, 2 stereo (4 mono) analog outputs, stereo analog input, plus S/PDIF digital I/O.
Roland Fantom XR Features
- 1U rackmount synthesizer/sampler with capacity for over 1GB of sounds
- 128-voice polyphony and expressive 4-tone stereo multiplex synthesis
- Flexible user sampling with .WAV/AIFF compatibility
- 128MB wave ROM expandable to 512MB via 6 optional SRX boards
- 16MB sample memory expandable to 528MB with optional DIMMs
- 3 MFX processors, plus separate reverb, chorus and mastering effects
- USB port and optional PC Card storage with up to 1GB capacity
- 2 stereo (4 mono) analog outputs
- Stereo analog input
- S/PDIF digital I/O
Roland Fantom XR Synth and Sampler Sound Module Specifications
Sound Generation
- Maximum Polyphony: 128 voices (shared with the sampling section)
- Parts: 16 parts
- Wave Memory: 128 MB (16-bit linear equivalent)
- Waveforms: 1,436
- Preset Memory:
- Patches: 1,024 + 256 (GM2)
- Rhythm Sets: 40 + 9 (GM2)
- Performances: 64
- User Memory:
- Patches: 256
- Rhythm Sets: 32
- Performances: 64
- Card Memory (PC card):
- Patches: 256
- Rhythm Sets: 32
- Performances: 64
- Effects:
- Multi-Effects: 3 systems, 78 types
- Chorus: 3 types
- Reverb: 5 types
- Input Effect: 6 types
- Mastering Effect: 3 bands Compressor
Sampling
- Data Format: 16-bit linear (File Type: WAV/AIFF)
- Maximum Sampling Time:
- Standard: 16 MB
- Mono: 180 seconds
- Stereo: 90 seconds
- Maximum (expanded with DIMM): 528 MB
- Mono: 99 minutes
- Stereo: 49 minutes
- Number of Samples:
- User Memory: 2,000 (maximum total approximately 16 MB)
- Card Memory: 7,000 (PC card)
- Sampling Frequency: 44.1 kHz (fixed)
Others
- Arpeggiator:
- Rhythm Pattern:
- Preset: 256 (32 groups)
- User: 256 (32 groups)
- Chord Memory:
- Display: Graphic 160 x 48 dots backlit LCD
- Connectors:
- Headphones Jack
- A (MIX) Output Jacks (L/MONO, R): 1/4 inch TRS phone type
- B Output Jacks (L, R): 1/4 inch phone type
- Input Jacks (L/MONO/MIC, R): 1/4 inch phone type
- MIDI Connectors (IN, OUT, THRU)
- USB Connector (supports file transfer and MIDI)
- Digital Audio Interface (COAXIAL INPUT/OUTPUT)
- AC Inlet
- Expansion Slots:
- SRX expansion boards: 6 slots
- RAM Expansion (DIMM): 1 slot (supports up to 512 MB)
- External Storage Device: PC card: 1 slot (SmartMedia)
- Power Supply:
- AC 117 V
- AC 230 V
- AC 240 V (50/60 Hz)
- AC 220 V (60 Hz)
- Included Accessories:
- Owner's Manual
- Sound/Parameter List
- Sample Data (Audio) CD
- CD-ROM (Editor, USB MIDI driver)
- Power Cord
- Optional Accessories: Wave Expansion Boards: SRX Series
- Dimensions (WxDxH): 18-15/16 x 14 x 1-13/16 inches (481 x 355 x 45 mm)
- Weight: 10 lbs 6 oz (4.7 kg)
|
|
|
Guaranteed Lowest Price
| |
|
Rate and Review this Product:
 | |
| | 2 people wrote reviews | |
| | AMS Customer from USA | | Overall Ranking: | | Quality:
|  | | Features:
| | | Ease of Use:
|  | | Value:
| | | Subject: | 3x the power than the fantom S | | Overall:
| Packs a punch! U get 3x the power than the fantom S, but in a rack. The XR is worth the bucks, althought I use it with a mpc 4000 and triton studio. It is another flagship in my studio. | |
| | AMS Customer from USA | | Overall Ranking: | | Quality:
| | | Features:
| | | Ease of Use:
| | | Value:
| | | Subject: | Roland XR Rack the New King of Racks! | | Overall:
| OVERALL:
Great sounding module w 128 note polyphony and 128mb Sound ROM, this will pretty much replace most peoples' JV/XV racks. Perfect to hook up to an 88 note MIDI controller for the awesome piano sound. Best piano I've heard on a synth, ever!
QUALITY:
Very good sound quality, typical Roland built like a tank!
FEATURES:
Almost same features as the Keyboard 'cept for the awesome Colour LCD.
EASE OF USE:
Fairly easy to use for a Rack, nice menu setup.
VALUE:
For $655 less than the keyboard its an awesome value. The new Roland flagship rack.
SOUND:
The piano is to die for and the acoustic sounds are the best in its class!
STYLE:
Classical, Jazz, Pop, Techno
MUSIC EXPERIENCE:
Classically trained, Solo live artist |
|
