| Product Specifications | Korg Grandstage X Digital Stage Piano Specifications
- Keyboard: RH3 (Real Weighted Hammer Action 3) keyboard, A0 - C8, velocity supported, aftertouch not supported
- Method of Synthesis and Maximum Polyphony:
- SGX-2 (Acoustic Piano Sound Engine)
- EP-1 (Electric Piano Sound Engine)
- AL-1 (Analog Modeling Sound Engine)
- CX-3 (Tonewheel Organ Sound Engine)
- VOX Organ (Transistor Organ Sound Engine)
- FC-1 (Transistor Organ Sound Engine)
- HD-1 (PCM Sound Engine)
- Maximum Polyphony: 128
- Preload PCM Storage Capacity: Approx. 25.5 GB (linear equivalent: approx. 51 GB)
- Number of Sounds: 700
- Favorite: 100 (including 20 preloads)
- Effects:
- Reverb types: HALL, STAGE, ROOM, SPRING, SHIMMER
- Delay type: DELAY, MOD DELAY, TAPE ECHO
- Audio In: Dyna Compressor, Exciter/Enhancer, Isolator, Multi-Mode Filter, Mastering Limiter, Limiter, Graphic EQ, Modern Compressor
- EQ: 3-band equalizer: LOW, MID, HIGH
- Analog Tone: Vacuum tube analog sound effects with Nutube
- Part Control Section: MAIN button, MAIN slider, LAYER button, LAYER slider, SPLIT button, SPLIT slider
- Unison Section: UNISON button, UNISON slider
- Key Touch Section: KEY TOUCH button, KEY TOUCH slider
- Rhythm Section: CHORD PROGRESSION button, KEY button, SETUP button, PLAY/STOP button, BASS MUTE button, TEMPO button
- Sound Select Section: 1[GRAND]~10[OTHERS] button, FAVORITE button
- Reverb/Delay section: REVERB/DELAY button, TYPE button, DEPTH slider
- EQ Section: ON/OFF button, LOW, MID, HIGH slider
- Analog Tone Section: ON/OFF button, DEPTH knob
- Other: Cursor UP/DOWN button, +/- button, function button, EXIT button, ENTER button, PANEL LOCK button, SYSTEM button, AUDIO IN button, power button
- Realtime Controller: Pitch bend wheel, modulation wheel, SW1 button, SW2 button
- Audio Output XLR (Left, Right):
- Connector: XLR-3-32 type (balanced) + LIFT-GND switch
- Output impedance: 600 ohm
- Maximum level: +16 dBu
- Load impedance: 10kO
- Audio Output (L/Mono, R):
- Phone connector: 6.3 mm TRS phone jack (balanced)
- Output impedance: 1.1k ohm (stereo output), 600 ohm (L/Mono terminals, mono output)
- Maximum level: +16 dBu
- Load impedance: 10k ohm
- Audio In:
- Phone connector: 6.3 mm TRS phone jack (unbalanced)
- MIC/LINE switch
- LEVEL knob
- Headphones:
- Connector: 6.3 mm stereo phone jack
- Output impedance: 50 ohm
- Maximum level: 150mW+150mW @32 ohm
- Control Input:DAMPER (half damper supported), SWITCH, PEDAL
- MIDI: IN, OUT
- Card Slot: SD Card Slot
- USB: USB TYPE B x 1
- Power Supply: AC power supply terminal
- Dimensions (W x D x H): 1,371 x 461 x 168 mm / 53.98” x 18.15” x 6.61” (excluding music stand)
- Weight: 25 kg / 55.12 lbs (excluding music stand)
- Power Consumption: 20W
- Included Items:
- AC Cord
- Music Stand
- Damper Pedal (DS-1H)
|
