| Product Specifications | Roland VR-6HD Direct Streaming Audio Visual Mixer Specifications
- Video Processing: 4:2:2 (Y/Pb/Pr), 8-bit
- Number of Video Channels: 6 channels
- File Format: MP4
- - Codec:
- - H.264, target bitrate up to 20,000 kbps
- - AAC LC, 16 bits, 48 kHz, stereo, target bitrate up to 384 kbps
- File Format: WAV
- - Codec: Linear PCM, 16 bits, 48 kHz, stereo
- - * If either the streaming and recording format or the file played by the video player exceeds 1080/30p, the streaming and recording and video player functions cannot be used simultaneously.
- - * If the bitrate setting for Streaming and Recording and the bitrate of the file played on Video Player exceeds 20,000 kbps, Streaming and Recording and Video player cannot be used simultaneously.
- Video Player:
- - File Format: MP4 (H.264, AAC), Average bit rate of 20,000 kbps or less, Maximum 1080/60p
- - * If either the streaming and recording format or the file played by the video player exceeds 1080/30p, the streaming and recording and video player functions cannot be used simultaneously.
- - * If the bitrate setting for Streaming and Recording and the bitrate of the file played on Video Player exceeds 20,000 kbps, Streaming and Recording and Video player cannot be used simultaneously.
- Still Image:
- - Bitmap File (.bmp) Maximum 1920 x 1080 pixels, 24-bit color, uncompressed.
- - PNG File (.png) Maximum 1920 x 1080 pixels, 24-bit color
- - JPEG File (.jpg, .jpeg) Maximum 1920 x 1080 pixels, 24-bit color
- Video Effects:
- - Transition: Cut, Mix (Dissolve/Fam/Nam), WIPE (8 types), SPLIT (2 types)
- - Composition: PinP x 2 (Square, Circle, Diamond), Keyer x 2 (Luminance Key, Chroma Key), DSK (Luminance Key, Chroma Key, Alpha Key, External Key)
- - Others: Multi-View (3 types), Flip horizontal, Flip vertical, Still Image capture, Still Image playback, Output fade (Audio, Video: White or Black), Test pattern output, Stream Delay
- Sample rate: 24 bits, 48 kHz
- Number of Audio Channels: 28 channels
- Audio Formats:
- - USB STREAM (input/output): Linear PCM, 24 bits, 48 kHz, 2 ch
- - Bluetooth (input): Linear PCM, 24 bits, 48 kHz, 2 ch
- - VIDEO IN: Linear PCM, 24 bits, 48 kHz, 2 ch
- - VIDEO OUT: Linear PCM, 24 bits, 48 kHz, 8 ch
- Audio Player:
- - File format: WAV (Linear PCM, 16 bits, 48 kHz/44.1 kHz, stereo)
- - * It can be stored up to 16 tracks in the internal memory.
- Audio Effects:
- - Channel Effects: High pass filter, Echo canceller, Anti-feedback, Noise gate, De-esser, Compressor, 4-Band equalizer, Voice changer, Delay, Auto mixing
- - Master Effects: Reverb, 4-Band equalizer, Compressor/Limiter, Loudness Auto Gain Control, Adaptive Noise Reduction, Low Frequency Cut, 15-Band GEQ, Delay
- - Others: Output fade, Test tone output
- Recording Media:
- - SDHC/SDXC card (sold separately)
- - USB flash drive (sold separately)
- - * SDXC card is required for video recording.
- Video Input Connectors:
- - VIDEO IN 1--6: HDMI type A x 6
- - * HDCP Supported
- - * Multi-format Supported
- Video Output Connectors:
- - VIDEO OUT 1--3: HDMI type A x 3
- - * HDCP Supported
- USB STREAM: USB Type-C (TM)
- Audio Input Connectors:
- - Analog:
- - AUDIO IN 1--6: Combo type (XLR, 1/4-inch TRS phone), phantom power DC 48 V (unloaded maximum), 14 mA (maximum load)
- - AUDIO IN 7/L, 8/R: RCA phono type
- - Digital:
- - USB STREAM: USB Type-C (TM)
- - Bluetooth
- - VIDEO IN 1--6: HDMI type A x 6
- Audio Output Connectors:
- - Analog:
- - AUDIO OUT 1/L, 2/R: XLR type
- - AUDIO OUT 3/L, 4/R: RCA phono type
- - PHONES: Stereo miniature phone type
- - Digital:
- - USB STREAM: USB Type-C (TM)
- - VIDEO OUT 1--3: HDMI type A x 3
- - Other Connectors
- - USB HOST: USB A type (for USB flash drive)
- - USB STREAM: USB Type-C (TM) (for remote control from PC and iPad)
- - Bluetooth: for remote control from iPad
- - CTL/EXP 1, 2:1/4-inch TRS phone type (for remote control from foot switch and expression pedal)
- - TALLY/GPIO: DB-25 type (Female)(Tally/GPO: 16, GPI: 8)
- - RS-232: DB-9 type (Male) (for Remote Control)
- - DIRECT STREAM: RJ45, 1000BASE-T (for Live Streaming and Remote Control)
- Input Level:
- - AUDIO IN 1--6: -64--+4 dBu (Maximum: +24 dBu)
- - AUDIO IN 7/L, 8/R: -10 dBu (Maximum: +10 dBu)
- Input Impedance:
- - AUDIO IN 1--6: 8.4 k ohms
- - AUDIO IN 7/L, 8/R: 10 k ohms
- Output Level:
- - AUDIO OUT 1/L, 2/R (XLR): +4 dBu (Maximum: +24 dBu)
- - AUDIO OUT 3/L, 4/R (RCA): -10 dBu (Maximum: +10 dBu)
- - PHONES: 92 mW + 92 mW (32 ohms)
- Output Impedance:
- - AUDIO OUT 1/L, 2/R (XLR): 600 ohms
- - AUDIO OUT 3/L, 4/R (RCA): 1 k ohm
- - PHONES: 33 ohms
- Bluetooth:
- - Ver 5.0
- - Profile Support: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
- - Codec: SBC (Support to the content protection of the SCMS-T method)
- Display: Graphic Type, 4.3", Wide QVGA (480 x 272 dots), backlite LCD (Color/Touch screen)
- Power Supply: AC adaptor
- Current Draw: 2.3 A
- Power Consumption: 55 W
- Dimensions (WxDxH): 14-5/8 x 9-9/16 x 3-15/16 inches
- Weight (excluding AC adaptor): 7 lbs 8 oz
- Accessories:
- - Startup Guide
- - Leaflet "USING THE UNIT SAFELY"
- - AC adaptor
- - Power cord
|
