The Shure MX410 is a low-profile, aesthetic designed surface mount mic with an adjustable 10" gooseneck. Featuring RF Filtering with CommShield technology & Bi-color LED status indicator
0 Reviews
Write a review
0% Interest
Payment Plan
Don’t sell your soul to a creditor to get the gear you need. At AMS, we want to lower the barriers to create. That’s why we offer in-house 0% financing, and you don’t even have to open a new line of credit! Spread out payments on your credit card to simplify financing and avoid hefty late fees or service charges. Cost shouldn’t interfere with your creativity.
Earn rewards every time you shop at AMS. You'll collect points on eligible purchases that turn into promotional savings on future gear, with points typically available several days after your order ships. All you need is a free AMS account — no credit card, financing, or payment plan required.
The more you shop, the more you earn. Create a free account and start earning from your very first eligible purchase. Rewards are applied as a discount on future eligible purchases.
Earn points on eligible purchases with AMS Rewards and turn them into savings on future orders, no credit card required. You can apply points at checkout once they’re available.
Eligible to earn $14.50 for this purchase
OR
6 Payments of $48.33 No Credit Check
Compare
Compare! Here are all the serial numbers of this model we have in stock. Compare them all and select your favorite!
Opt in for Notifications on this product for the price drops, stock changes and promotions
The MX410 surface mount version is a gooseneck microphone with a Bi-Color LED or light ring status display. It has a 10" gooseneck and is suitable for boardrooms and other sites where aesthetics are important.
Shure MX410LPDF/C 10in Cardioid Gooseneck Mic Features:
Gooseneck length: 10 inch / 25.4 cm
Low profile, aesthetic design
Wide dynamic range and smooth frequency response
RF filtering with CommShield technology
Status indicator: Bi-Color LED at gooseneck bottom or red light ring on gooseneck top
Capsule options: None, Cardioid, Supercardioid
Preamplifier Options:
MX400DP: Desktop Base for MX405, MX410 and MX415 models
MX890: Wireless Desktop Base for MX405, MX410 and MX415 models
MX400SMP: Surface Mount Preamp for MX405, MX410 and MX415 models
MXW8: Wireless Desktop Base for MX405, MX410 and MX415 models
ULXD8: Wireless Desktop Base for MX405, MX410 and MX415 models
Warranty: 2 Years on Wired Microphones; 1 Year on Wireless Systems & Components; 1 Year on Personal Monitors & Components: 1 Year on Circuitry Products.
Output Impedance: EIA Rated at 150 Ω (170 Ω actual)
Output Configuration: Active Balanced
Sensitivity (@ 1 kHz, open circuit voltage):
Cardioid: -35 dBV/Pa (18 mV)
Supercardioid: -34 dBV/Pa (21 mV)
Maximum SPL (1 kHz at 1% THD, 1 kΩ load):
Cardioid: 121 dB
Supercardioid: 120 dB
Self Noise (A-weighted):
Cardioid: 28 dB SPL
Supercardioid: 27 dB SPL
Signal-to-Noise Ratio (Ref. 94 dB SPL at 1 kHz):
Cardioid: 66 dB
Supercardioid: 68 dB
Mini-shotgun: 68 dB
Dynamic Range (1 kΩ load, @ 1 kHz): 93 dB
Common Mode Rejection: 10 to 100,000 kHz, 45 dB, minimum
Clipping Level at 1% THD: -8 dBV (0.4 V)
Polarity:
3-pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
5-pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4 relative to pin 2 of output XLR connector
Weight:
MX405: 0.054 kg (0.119 lbs)
MX410: 0.068 kg (0.150 lbs)
MX415: 0.07 kg (0.154 lbs)
MX400DP: 0.516 kg (1.138 lbs)
MX400SMP: 0.125 kg (0.275 lbs)
Logic Connections:
LED IN: Active low (=1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
LOGIC OUT: Active low (=1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kO).
Mute Switch Attenuation: -50 dB minimum
Cable: MX400DP, 6.1 m (20 ft) attached cable with shielded audio pair terminated at a 3-pin male XLR and three unterminated conductors for logic control
Output Impedance: EIA Rated at 150 Ω (170 Ω actual)
Output Configuration: Active Balanced
Sensitivity (@ 1 kHz, open circuit voltage):
Cardioid: -35 dBV/Pa (18 mV)
Supercardioid: -34 dBV/Pa (21 mV)
Maximum SPL (1 kHz at 1% THD, 1 kΩ load):
Cardioid: 121 dB
Supercardioid: 120 dB
Self Noise (A-weighted):
Cardioid: 28 dB SPL
Supercardioid: 27 dB SPL
Signal-to-Noise Ratio (Ref. 94 dB SPL at 1 kHz):
Cardioid: 66 dB
Supercardioid: 68 dB
Mini-shotgun: 68 dB
Dynamic Range (1 kΩ load, @ 1 kHz): 93 dB
Common Mode Rejection: 10 to 100,000 kHz, 45 dB, minimum
Clipping Level at 1% THD: -8 dBV (0.4 V)
Polarity:
3-pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
5-pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 4 relative to pin 2 of output XLR connector
Weight:
MX405: 0.054 kg (0.119 lbs)
MX410: 0.068 kg (0.150 lbs)
MX415: 0.07 kg (0.154 lbs)
MX400DP: 0.516 kg (1.138 lbs)
MX400SMP: 0.125 kg (0.275 lbs)
Logic Connections:
LED IN: Active low (=1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
LOGIC OUT: Active low (=1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kO).
Mute Switch Attenuation: -50 dB minimum
Cable: MX400DP, 6.1 m (20 ft) attached cable with shielded audio pair terminated at a 3-pin male XLR and three unterminated conductors for logic control
Operating Temperature: –18–57°C (0–135°F)
Storage Temperature: –29–74°C (–20–165°F)
Relative Humidity: 0–95%
Phantom Power: 48–52 V DC, 8.0 mA
