| Product Specifications |
- Dimensions (W x H x D): 1,089 x 117 x 347 mm / 42-7/8" x 4-5/8" x 13-11/16"
- Weight: 7.6 kg / 16 lbs 12 oz
- Keyboard:
- Number of Keys: 76
- Type: Semi-weighted FSB Keyboard
- Initial Touch: Yes
- Aftertouch: No
- Tones/Sounds:
- Tone Generator: Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise
- Maximum Polyphony: AWM2: 128 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 12 (max.)
- Multi Timbral Capacity: 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part
- Wave: Preset: 10.7 GB (when converted to 16-bit linear format), User: 1.9 GB
- Performance 3,427 Filter: 18 types
- Effects: Reverb x 13 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)
- Performance Recorder:
- Note Capacity: 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song)
- Note Resolution: 480 ppq (parts per quarter note)
- Tempo (BPM): 5 – 300
- Sequence Formats: MONTAGE M/MODX M original format, SMF formats 0, 1
- Arpeggio: Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types
- Sequencer:
- Patterns: 128 patterns
- Pattern Tracks: 16 Sequence tracks
- Pattern Recording Type: Real time replace, Real time overdub
- Songs: 128 songs
- Song Tracks: 16 Sequence tracks, Tempo track, Scene track
- Song Recording Type: Real time replace, Real time overdub, Real time punch in/out
- USB Audio Interface: [Sampling Frequency = 44.1 kHz] Input: 4 channels (2 stereo channels), Output: 10 channels (5 stereo channels) [Sampling Frequency = 44.1kHz / 48kHz / 96kHz] Input: 2 channels (1 stereo channel), Output: 2 channels (1 stereo channel)
- Controllers: Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Control Slider x 8, Knob x 4, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable swich x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch
- Display: 7" TFT Color Wide VGA LCD touch screen
- Connectors: USB [TO DEVICE], USB [TO HOST], MIDI [IN]/[OUT], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
- Power Consumption: 19W (When using PA-300C AC adaptor)
- Accessories:
- AC adaptor: PA-300C
- Quick guide
- Cubase AI Download Information
- Expanded Softsynth Plugin for MONTAGE M/MODX M
- Information About downloading manuals
- Welcome card
- Live Sets: Preset: 256, User: 2,048
|
